Denso G3p017 Diesel Common Rail Nozzle With High Speed Steel
Name: Denso Common Rail Nozzle
Model: G3p017
Material: High Speed Steel
You could find more other models list at the end of this page
| NOZZLE MODEL |
INJECTOR MODEL |
ENGINE |
APPLICATION |
| G3S1 |
295050-0011/ R2AA-13-H50 |
R2, R2AA, 200MPa, MZR-CD |
MAZDA 3,6,CX-7 2.2D |
| G3S2 |
295050-0820/ 007/ 23670-30190/ 30380 |
1KD-FTV D4D, TOYOTA 200 EURO 4 |
TOYOTA Dyna 3.0D |
| G3S3 |
295050-005#/ 55567729 |
A17DTE, E, F, S, CDTI,1.7D,EURO 5 |
Chevrolet Cruze, Trax, Opel Astra, Corsa, Meriva, Mokka, Vauxhall |
| G3S4 |
295050-012#/ 1465A323 |
MITSUBISHI 4N13 EURO 5 |
MITSUBSIHI |
| G3S5 |
295050-0152/ 7153/ 8-97622719-2 |
ISUZU |
ISUZU |
| G3S6 |
295050-018#/ 052#/ 020#/ 046#/ 053#/
39365/ 30400/ 09350/ 23670-0L090 |
HILUX/ LAND CRUISER
1KD/ 2KD-FTV EURO 4 |
TOYOTA VIGO 3.0/ 2.5 VNT |
| G3S7 |
23670-0L100/ 295050-0190
295050-0530/ 30410/ 0470 |
Hilux 1KD-FTV 3.0L
Hilux 2KD-FTV 2.5L |
TOYOTA |
| G3S8 |
295050-0250/ 16613-AA030 |
SUBARU 2.0 |
SUBARU 2.0 |
| G3S9 |
295050-008#/ 083#/ 23670-30390 |
1KD-FTV D4D, TOYOTA 200 EURO 4 |
TOYOTA |
| G3S10 |
295050-0300/ 16600-5X00A |
NISSAN Navara YD25 2.5L EURO 5 |
NISSAN |
| G3S11 |
295050-0260/ ME306476 |
MITSUBSIHI Fuso 6M60-9AT EURO 5 |
MITSUBSIHI |
| G3S12 |
295050-0231/ 0920/ 23670-E0400/ E0540 |
HINO J05E/ J06/ J08E |
HINO |
| G3S14 |
295050-0323/6073/ 8-98110607-# |
ISUZU 4HK1 N SERIES 5.2L |
ISUZU |
| G3S15 |
295050-0340 |
HYUNDAI MIGHTY |
HYUNDAI |
| G3S16 |
295050-0331/ 370-7280 |
CATERPILLAR C4.4 / C7.1 |
CATERPILLAR |
| G3S17 |
259050-0610/ RE543352/RE543605
SE502556 |
JOHN DEER |
JOHN DEER |
| G3S18 |
295050-0600
RE543606/ RE543352/ SE502556 |
JOHN DEER |
JOHN DEER |
| G3S19 |
295050-059#/ 086#
RE545562/ RE543351/ SE502671 |
JOHN DEER |
JOHN DEER |
| G3S20 |
295050-0361/ 370-7281 |
CATERPILLAR C4.4/ C7.1 |
CATERPILLAR |
| G3S21 |
295050-0380 |
XICHAI |
|
| G3S22 |
295050-0401/ 370-7282 |
CATERPILLAR |
CATERPILLAR |
| G3S23 |
295050-0410/ 3454124/ 370-7286 |
PERKINS/ CAT C4.4 |
CATERPILLAR |
| G3S24 |
295050-042#/ 3454125/ 370-7287 |
PERKINS |
|
| G3S25 |
295050-043#/ 4180 3462926 |
|
|
| G3S28 |
295050-0451/ 0351 295050-2510/ 8880
295050-1581/ 2981 8-97431888-0/ 8-97622035-1 |
ISUZU |
ISUZU |
Shipping
We partner with major international shipping companies like DHL, UPS, FedEx, etc.And we ship the heavy big machine by sea for all over the world! This strategic collaboration allows us to offer you a wide range of shipping options, tailored to your specific requirements and budget. From express delivery for urgent orders to cost-effective sea freight for larger items, we'll ensure your products arrive at their destination safely and on schedule.
The working process of the common rail system
Fuel supply: The fuel pump draws diesel from the fuel tank and pumps it to the high-pressure common rail at high pressure. The high-pressure common rail stores the high-pressure fuel to keep the fuel in a high-pressure state.
Fuel injection control: The ECU calculates the appropriate fuel quantity and injection timing based on the engine operating conditions monitored by sensors, such as engine speed, load, air temperature, etc., and then sends control signals to the fuel injectors.
Fuel injection process: After the fuel injector receives the control signal from the ECU, it opens the solenoid valve of the injector, and the high-pressure fuel is injected into the combustion chamber through the fuel injector at extremely high pressure. The fuel injection time and the amount of fuel injected are precisely controlled by the ECU according to the actual needs of the engine.
